PuraVida
HG Basin mixer PuraVida chrome with
Surfaces: chrome___Article Number: 15074008
Description
Technology
product features
· ComfortZone 110
· laminar spray
· flow rate: 5 l/min
· adjustable spray former
· joystick ceramic cartridge
· pop-up waste set G 1
· suitable for continuous flow water heaters
· connection dimension: DN15
Product image
Scale drawing
More details online on the website_www.hansgrohe-int.com_We look forward for your visit
Page
1/3
PuraVida
HG Basin mixer PuraVida chrome with
Surfaces: chrome___Article Number: 15074008
Exploded Drawing
Year of production: >02/11
More details online on the website_www.hansgrohe-int.com_We look forward for your visit
Page
2/3
PuraVida
HG Basin mixer PuraVida chrome with
Surfaces: chrome___Article Number: 15074008
Spare part list
Year of production: >02/11
Pos.
Description
Article Number
PC
PU
1
handle
95287000
12
1
2
escutcheon Ø 37 mm
95288000
10
1
3
O-ring 33x1,5
98164000
1
1
4
nut
97157000
6
1
5
O-ring 30x1,5
98433000
6
1
6
O-Ring 30x2
98186000
1
1
7
cartridge, assy
96783000
13
1
8
O-ring 21,95x1,78
95169000
1
1
9
adapter for cartridge
95289000
7
1
10
O-ring 26x2
98147000
1
1
11
aerator M24x1 (5 l/min)
95282000
6
1
12
special tool
95290000
5
1
13
flat seal
98749000
2
1
14
fixing set
13961000
7
1
15
lever collar
97548000
1
1
16
connection hose 450 mm M8x0,75 G½
97443000
6
1
17
pull rod
96657000
4
1
18
O-ring 7x1,5
98422000
1
1
a
pop up waste
94159000
13
1
b
fixation extension 35 mm
13898000
12
1
c
service tool for disassembling the handle
92124000
15
1
d
push-open waste set
50100000
0
1
