Raindance Select
Raindance Select S 300 1jet Showerpipe
Surfaces: chrome___Article Number: 27114000
Description
Article Details
product features
· overhead shower Raindance S 300 Air
Price excl. VAT
· shower head size: 300 mm
820,00-£
Technology
· spray type: RainAir
· flow rate RainAir spray (at 0.3 MPa): 17 l/min
· operating pressure: min. 2 bar / max. 10 bar
· fully chrome-plated spray disc
· shower arm length: 460 mm
· swivel shower arm
· thermostat Ecostat Comfort
· safety lock at 40° C
· adjustable hot water limitation
· outlets controlled via turning handle
· installation type: exposed installation
· connection dimension DN15
· connection thread G ½
· centre distance 150 mm ± 12 mm
· height-adjustable hand shower holder
· scope of supply: wall bar spacer (grey)
consists of
· Isiflex shower hose 1.60 m (#28276XXX)
· Raindance Select S 120 3jet hand shower
(#26530XXX)
Optional Accessoires
· Wall bar spacer (#98681XXX)
Product image
Scale drawing
More details online on the website_www.hansgrohe-int.com_We look forward for your visit
Page
1/5
Raindance Select
Raindance Select S 300 1jet Showerpipe
Surfaces: chrome___Article Number: 27114000
Flowchart
More details online on the website_www.hansgrohe-int.com_We look forward for your visit
Page
2/5
Raindance Select
Raindance Select S 300 1jet Showerpipe
Surfaces: chrome___Article Number: 27114000
Installation examples
More details online on the website_www.hansgrohe-int.com_We look forward for your visit
Page
3/5
Raindance Select
Raindance Select S 300 1jet Showerpipe
Surfaces: chrome___Article Number: 27114000
Exploded Drawing
Year of production: 11/11 - 09/12
More details online on the website_www.hansgrohe-int.com_We look forward for your visit
Page
4/5
Raindance Select
Raindance Select S 300 1jet Showerpipe
Surfaces: chrome___Article Number: 27114000
Spare part list
Year of production: 11/11 - 09/12
Pos.
Description
Article Number
Price
PU
1
tile-matching-disk
98681000
£ 12,30
1
2
wall flange
98673000
£ 47,40
1
3
mounting set
98716000
£ 9,48
1
4
escutcheon Ø 80 mm
98672000
£ 57,60
1
5
shower arm
98360000
£ 270,00
1
6
O-ring 17x2,5
98387000
£ 1,92
1
7
escutcheon Ø 68 mm
96467000
£ 12,30
1
8
noise reduction
96429000
£ 3,48
1
9
set of S-unions
94140000
£ 30,60
1
10
O-ring 17x2
98199000
£ 1,92
1
11
head shower
95924000
£ 510,00
1
12
air jet
95794000
£ 19,20
1
13
handshower
28587000
-
1
14
filter insert
97708000
£ 3,48
1
15
shower hose Isiflex'B 1,60 m
28276000
-
1
16
support, assy
95480000
£ 47,40
1
17
pipe 1035 mm
95925000
£ 106,80
1
18
handle
95836000
£ 19,20
1
19
handle fixing set
95843000
£ 5,76
1
20
safety set
95839000
£ 12,30
1
21
O-ring 26x1,5
98390000
£ 9,48
1
22
nut
98913000
£ 12,30
1
23
thermostat cartridge
98282000
£ 67,20
1
24
O-ring 14x2
98129000
£ 1,92
1
25
shut off unit with selector
98283000
£ 47,40
1
26
stop ring for flow control
95927000
£ 19,20
1
27
set of nuts
96157000
£ 19,20
1
28
non return valve
96737000
£ 19,20
1
29
O-ring 17x1,5
98137000
£ 1,92
1
30
filter packing
96922000
£ 5,76
1
31
hollow set screw M6x8
98444000
£ 1,92
1
32
O-ring 12x2,25
98382000
£ 1,92
1
33
hollow set screw M4x10
97667000
£ 1,92
1
a
back flow preventor cartridge
92268000
£ 25,20
1
b
pipe 930 mm
95917000
£ 67,20
1
